H/IH Interchange Valved Female Coupler

Name: H/IH Interchange Valved Female Coupler
Brand: Dixon Valve
SKU: ID378209
Availability: InStock

Brand

Dixon Valve

Manufacturer

N/A

Part Number

10VF10

GTIN

89109882274

Condition

0 Reviews

0 Questions | 0 Answers

Product Description

Dixon, 10VF10, V-Series 1-1/4" Snap-Tite H/IH Interchange Steel Valved Female Coupler, 1-1/4" NPTFConstructionMachined components are manufactured using solid bar stockStainless steel balls, retaining rings and springs maximize corrosion resistance and extend service lifeSteel componentry is plated using ROHS Compliant Trivalent ChromeSteel coupler sleeves are hardened to resist deformation and maximize service lifeTubular 'TV' valves are constructed from steel bar stock and are designed for optimum performance in pneumatic applicationsNitrile (Buna-N) seals are standardAll couplers incorporate a PTFE anti-extrusion ring to protect the seal components from dynamic impulse damageValve O-rings are retained by a unique seal-groove profile and are field replaceableAvailable OptionsContact Us for all available option addersStandard seal options include: FKM, EPDM, Steam-EP, FDA FKM, Mil-Nitrile, Fuel Nitrile and SiliconeKalrez® seal options include: 4079, 6375 and 7075Valve options include: Unvalved, tubular, steel, brass and 316 stainless steelSleeve options include: Sleeve-lock, Flanged and Silicone-flangedOxy-clean treatment is availableCompatibility & Interchange DataInterchangeable to MIL-C-51234Interchangeable with Snap-Tite H/IH Series and Faster TNVNoteMinimum burst pressure ratings were established under laboratory conditions using a Static Burst Unit (SBU). For high impulse applications and to meet Det Norske Veritas (DNV) compliance, the burst pressure must be divided by four (4) to ensure a 4:1 safety factor during system operation.

Available Colors

N/A

Available Sizes

N/A
