Mark-10, M4-500, Series 4 Performance Digital Force Gauge, 500 lbF/ 8000 ozF/ 250 kgF/ 2500 N/ 2.5 kNSeries 4 digital force gauges are designed for tension and compression force testing in numerous applications across virtually every industry. The gauges feature a sampling rate of 3,000 Hz, producing accurate results under a wide range of test conditions. Accuracy is ±0.2% of full scale, and resolution is 1/2000. A large, backlit graphics LCD displays large, legible characters, while the simple menu navigation allows for quick access to the gauges' many features and configurable parameters. Data can be transferred to a PC or other data collector via USB, RS-232, Mitutoyo (Digimatic), or analog outputs.Includes:Carrying caseChiselConeV-grooveHookCouplingFlatExtension rodUniversal voltage AC adapterBatteryQuick-start guideUSB cableResource CD (USB driver, MESUR™ Lite software, MESUR™gauge DEMO software, and user's guide)NIST-traceable certificate of calibrationOn-board data memory for up to 50 readings is included, as are statistical calculations and output to a PC. Integrated set points with indicators are ideal for pass-fail testing and for triggering external devices such as an alarm, relay, or test stand. The gauges are overload protected to 150% of capacity, and an analog load bar is shown on the display for graphical representation of applied force.An ergonomic, reversible aluminum design allows for hand held use or test stand mounting for more sophisticated testing requirements. Series 4 digital force gauges are directly compatible with Mark-10 test stands, grips, and software. Series 5 force gauges are directly compatible with Mark-10 test stands, grips, and software.The gauges include MESUR™ Lite data acquisition software. MESUR™ Lite tabulates continuous or single point data. One-click export to Excel allows for further data manipulation.Features:High-speed 3,000 Hz sampling rateUSB, RS-232, Mitutoyo, and analog outputsLarge backlit graphic display50-point data memory with statistics (min, max, mean, standard deviation) and outputsLive load bar graph with set point markersProgrammable set points, with alarms and outputsPeak readings and set points always displayed5 selectable units of measurementConfigurable audio alarms and key tonesPassword protection, configurable for individual keys and calibrationDisplay Indicators:Focus on Engineering: Reversible Housing.
