DF-Series Steel DQC Female Plug

Dixon, D4BF4, DF-Series 1/2' Steel DQC Industrial Female Plug 1/2' BSPPSpecificationsRated pressure when connected with Brass D-Series Automatic Couplers: 500 PSI (35 bar) Maximum Working and 14,000 PSI (965 bar) BurstRated pressure when connected with Steel F-Series Manual Couplers: 500 PSI (35 bar) Maximum Working and 15,500 PSI (1,070 bar) BurstConstructionMachined components are manufactured using solid bar stockSteel componentry is plated using ROHS Compliant Trivalent ChromeCompatibility & Interchange DataFoster 3, 4, 5 and 6 SeriesParker 30 - Series Automatic Interchange & Parker 20-Series Manual InterchangeHansen 3000, 4000, 5000 and 6000 & Hansen 1000, 400 and 500How it worksTo disconnect, begin by holding the hose on the nipple side with three of your fingers, leaving your thumb and index finger freeGrab the sleeve with your thumb and index finger and begin to pull the sleeve towards the palm of your handAfter pulling the sleeve, the nipple will move out of the coupler slightly. Continue to hold the hose and coupler sleeve until all air is fully exhaustedAfter the line is fully exhausted, you are able to safely separate the nipple from the couplerSafety notesIt is important to be safe when installing quick disconnect couplings into a pneumatic circuit. Never install a pneumatic coupling directly into an air tool, use a piece of hose that is at least 18" long, between the tool and the coupling, to prevent damage to the coupling. To protect the operator, safety devices, such as a safety check valve and safety cable should be installed in case there is a hose or coupling failure.
