Copied HT-Series Flushface Bulkhead Coupler
HT-Series Flushface Bulkhead Coupler
Dixon, 4HTRB5, HT-Series 1/2" Flushface Male Bulkhead Coupler 1" ORFSSpecificationsRated pressure for connected Steel Coupler and Steel Plug: 5,000 PSI (345 bar) Maximum Working and 20,000 PSI (1,379 bar) burstRated pressure for uncoupled Steel Coupler: 5,000 PSI (345 bar) Maximum Working and 20,000 PSI (1,379 bar) burstFeaturesHigh flow performance, compact profileEasily rebuildable!Bulkhead mountable sleeve for breakaway, multi-plate or Blindmate installationsDORS (dual opposing retention spheres) retention system prevents valve stem ejection during surge flow and pressure spike conditionsConstructionMachined components are manufactured using solid bar stockStainless steel balls, retaining rings and springs maximize corrosion resistance and extend service lifeSteel componentry is plated using ROHS Compliant Trivalent ChromeSteel coupler sleeves are hardened to resist deformation and maximize service lifeCouplers have polyurethane valve stem O-Ring, with a temperature range of -65° to +212°FAncillary coupler seals are Nitrile (Buna-N), with a temperature range of -40°F to +250°FPTFE or TPC-ET Anti-Extrusion ring protects main coupling valve seal from dynamic impulse pressure damageAvailable OptionsContact Us for all available option addersStandard seal options include: FKM, EPDM, FDA FKM, Mil-Nitrile, Fuel Nitrile and SiliconeKalrez® seal options include: 4079, 6375 and 7075Oxy-clean treatment is availableCompatibility & Interchange DataInterchangeable to ISO16028Parker FEM-Series, Snap-Tite 74-Series, Hansen FF, Aeroquip/Eaton FD89, Stucchi A/FIRG, Faster FFH/2FFN/2FFI, Safeway FF49-Series.
Price Comparison
| Seller | Contact Seller | List Price | On Sale | Shipping | Best Promo | Final Price | Volume Discount | Financing | Availability | Seller's Page |
|---|---|---|---|---|---|---|---|---|---|---|
|
BEST PRICE 1 Product Purchase
|
|
$56.59 | $56.08 |
|
$56.08 | See Site | Visit Store |
