Binocular Inverted Metallurgical Microscope

Meiji Techno, IM7100, Binocular Inverted Metallurgical Microscope with 6V,30W HalogenIncludes:MA814/05: Siedentopf type binocular head – inclined at 30°, Interpupillary adjustment 53mm to 75mm graduated diopter on left eyetube (30mm I.D. eyetubes) with depolarizerMA817 (x 2): SWH 10X Widefield high eyepoint eyepiece, Field No. 22, (accepts 25mm diameter reticle)MA906 (x 2): Rubber Eyeguards, foldable (paired)MA870: Planachromat E5X, ∞ objective N.A. 0.10, W.D. 20.0mm, F.L. 40.0, ∞ Infinity CorrectedMA871: Planachromat E10X, ∞ objective N.A. 0.25,W.D. 7.48mm, F.L. 20.0, ∞ Infinity CorrectedMA872: Planachromat E20X, ∞ objective N.A. 0.40, W.D. 5.20mm, F.L. 10.0, ∞ Infinity CorrectedMA873: Planachromat E50X, ∞ objective N.A. 0.75, W.D. 0.38mm, F.L. 4.0, ∞ Infinity CorrectedStage: 180mm (X) x 245mm (Y) Plain stage (Factory installed)Focus Mechanism: Ergonomically low positioned, coaxial coarse and fine focus knobs with adjustable tensionFront Photo Port: Front mounted camera port suitable for CCD, 35mm SLR, or digital cameras with optional camera adapters to facilitate a wide range of camera and video equipmentMA475/05: LB100 Blue clear 19.5mm diameter filter in metal mount, fits 25mm filter slotMA476: G533 Green clear 19.5mm diameter filter in metal mount, fits 25mm filter slotMA774: ND50 Neutral density filter, 19.5mm diameter filter in metal mount, fits 25mm filter slotMA497: Polarizing filter, 19.5mm diameter filter in metal mount, fits 25mm filter slotMA809/10: Removable AC Electric cord with plug for 115V modelsMA326: Halogen bulb, 6V 30W (Factory installed)MA327: Fuse 3A, Replacement (Factory installed)MA714: Dust coverManual: IM7000 Meiji Techno Instruction ManualIM7100: Binocular Inverted Brightfield Metallurgical Compound microscope with an integrated 6V/30W vertical Koehler Halogen illuminator with variable intensity control and automatic voltage sensing power supply provides excellent specimen illumination and contrast. Quintuple nosepiece and auto voltage sensing power supply. Infinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units. All of our IM7000 Series controls are ergonomically positioned to provide comfort and extended ease of use for the operator. Meiji's IM Series is well suited for examination of mounted metallurgical specimens or for routine quality inspections such as, microstructure analysis, various materials testing, QA and QC examination and photomicrography.The Meiji Techno IM7000 Series Inverted Brightfield Metallurgical Microscope have an ergonomic slim triangular shaped design that saves bench space to maximize efficiency and offers ultimate stability with its cast aluminum alloy frame. This is the most rugged Inverted Microscope from Japan. Infinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units. All of our IM7000 Series controls are ergonomically positioned to provide comfort and extended ease of use for the operator. An integrated 6V/30W vertical Koehler halogen illuminator with variable intensity control and automatic voltage sensing power supply provides excellent specimen illumination and contrast. The IM7000 Series is designed to meet your most diverse needs for materials research. Meiji's IM Series is well suited for examination of mounted metallurgical specimens or for routine quality inspections such as, microstructure analysis, various materials testing, QA and QC examination and photomicrography. The IM7000 Series offers crisp, distortion-free, high resolultion images in multiple modes of operation the built in photo port on the front of the body makes image documentation quick and easy. Contrast methods available include: Brightfield and Polarized Light observation modes.Features:All models come standard with ∞ Infinity Corrected Optical objectives (F=200)Viewing heads are supplied with a Siedentopf type binocular head, inclined at 30° or a trinocular Siedentopf head inclined at 45°. Interpupillary distance is adjustable from 53mm to 75mm. A graduated diopter adjustment is provided as a standard feature on the left eyetube of all units.Eyepieces are SWH10X, widefield, high eye point eyepieces, F.N. 22, with a 25mm reticle mount, SWH15X, SWH20X and SWH10X-F focusing eyepieces are available as an option. Anti-reflection coated, manufactured with a large diameter lens with more optical elements and high eyepoint to reduce eye fatigue and accommodate eyeglass wearers, and come equipped with a fold-down rubber eye-guardsInfinity Corrected Planachromat 5X, 10X, 20X and 50X objectives are standard in all units. Objectives are made with extra-low-dispersion glass ans utilize new advanced multilayer ani-reflection coatings. The advanced technology used in designing and creating objectives result in an objective with a higher resolving power, higher image contrast, wider field of view, improved flatness of field, and a sharp image with a minimum of flare and ghosting. The objectives are color corrected for chromatic aberration in the red and blue regions of the spectrum and offer and exceptional flat field of view.Quintuple Nosepiece , side facing, with positive precision detent, click stopsPlain stage 180mm (X) x 245mm (Y) dimensionsOptional Mechanical Stage with drop down post available, 112mm (X) x 72mm (Y) movement.Focus travel, 9mm total, 1.0mm up and 8mm down, Rotation of fine focus: 0.2mm per revolution.Vertical Koehler illuminator equipped with 6V 30W Halogen bulb, Variable rheostat and automatic voltage sensing power supply are incorporated as standard.Cast aluminum alloy body for rigidity and exceptional stability.
