Copied 3/8" Tube OD Instrumentation Rear Ferrule
3/8" Tube OD Instrumentation Rear Ferrule
ApplicationsApplications include: high pressure, high temperature, nitrogen, helium, flammable gases, hydraulic gases and corrosive media.FeaturesDouble collet (ferrule) swaging actionTwo positive seal pointsConstructionASTM material construction316 stainless steelCompatibility & Interchange DataFully interchangeable with Swagelok® and Parker A-Lok® fittingsInstallationCut tubing squarely and clean tube end thoroughly to remove burrs.Insert tubing into the assembly making sure the tubing seats firm against the shoulder of the body and the nut is finger tight.Tighten the nut with a wrench 1-1/4 turns, while holding the body with a second wrench.NoteInstrumentation fittings come completely assembled.Safety notesNever connect, disconnect or remake a fitting with pressure in the system.Make sure all fittings are properly installed.It is not recommended to go beyond the pressure rating of the tubing. Elongation could occur in the tubing, shrinking the wall thickness and cause potential harm.For proper sealing it is recommended that the tubing and fittings be of like material.Always use proper thread lubricant and sealants on tapered pipe threads.Never bleed a system by loosening a fitting.
Price Comparison
| Seller | Contact Seller | List Price | On Sale | Shipping | Best Promo | Final Price | Volume Discount | Financing | Availability | Seller's Page |
|---|---|---|---|---|---|---|---|---|---|---|
|
BEST PRICE 1 Product Purchase
|
|
$2.47 | $2.46 |
|
$2.46 | See Site | Visit Store |
Reviews
Questions & Answers
