12 gallon, Semi-Recessed Waste Receptacle(recesses 2'; projects 6-11/16')Product Materials:CABINET: 0.030-inch/22-ga. (0.76 mm) stainless steel with exposed surfaces in architectural satin finish. Welded construction with seamless corners and burr-free edges.FLANGE: 0.030-inch/22-ga. (0.76 mm) stainless steel with exposed surfaces in architectural satin finish. One-piece seamless construction, 1' wide with 1/4' return.WASTE CONTAINER: 0.036-inch/20-ga. (.92mm) stainless steel with exposed surfaces in architectural satin finish. All welded construction. Secured to cabinet with tumbler lock keyed like other Bradley units. Front of cabinet has matching curvature to other Bradley Diplomat washroom accessories.Capacity:Waste Container - gal. (1.6 cu. ft.)OperationReceptacle removable for servicing by unlocking waste container. Operates with less than 5 lbs. of force.Installation:Verify all rough-in dimensions prior to installation. Recessed unit requires rough wall opening 15-3 ⁄4'W x 29-3 ⁄16'H x 4'D. Secure to framing with mounting screws (not included) at holes provided. Shim at screw points as required.Guide Specification:12 gal./1.6 cu. ft. Capacity waste receptacle in [recessed] [semi-recessed] [surface-mounted] wall cabinet with self-trimming flange. Waste receptacle face formed with contemporary contours, radii, and finish matching related accessories in manufacturer's designer series. Waste receptacle removable from cabinet with keyed tumbler lock. Universal keying. Formed from stainless steel sheet with satin finish on exposed surfaces, fully welded, with seamless corners and burr-free edges: cabinet and flange 0.036-inch/20-ga. thick, waste receptacle 0.036-inch/20ga. thick.Overall dimensions: 17-1 ⁄8'W x 30-5 ⁄8'H x 8-11/16'D.MasterFormat Title: Commercial Toilet AccessoriesMasterFormat Number: 10 28 13.13OmniClass Title: Toilet and Bath SpecialtiesOmniClass Code: 23.31.25.00.
