Copied 1/8" Tube OD Flareless Bite Ferrule
1/8" Tube OD Flareless Bite Ferrule
ApplicationsChemical, pulp and paper, oil and gas refineries, military, air compressors and machine toolsWell-suited for a variety of processing and general industry hydraulic applicationsUseIdeally suited for use with tubing having medium to extra heavy wall thicknesses.Fittings are suitable for sub-zero through elevated temperature applicationsSpecificationsExceeds Military (MIL F18866) and SAE J514 standardsFeatures3 piece design including only one ferrule eliminates possible make-up errors that may occur using a twin ferrule tube fitting.Minimal risk of improper assembly as the ferrule visibly bites into the tubing which allows installer to visually inspect the bite quality.InstallationCut, de-burr and clean tubingPre-set ferrule onto tubingInspect ferrule bite in tubing by disassembling the fitting and visually inspecting the de-burred end of the tube for slight indentation.Finger tighten nut and then further wrench tighten nut another 1/3" to 1/2" turn.NoteTemperature rating is limited by the material chosenPressure ratings are determined by the size (OD) and wall thickness (inches/mm) of the tubing on which they are to be installed.
Price Comparison
| Seller | Contact Seller | List Price | On Sale | Shipping | Best Promo | Final Price | Volume Discount | Financing | Availability | Seller's Page |
|---|---|---|---|---|---|---|---|---|---|---|
|
BEST PRICE 1 Product Purchase
|
|
$2.12 | $2.10 |
|
$2.10 | See Site | Visit Store |
