Copied W-Series Female Plug 1/4" Brass
W-Series Female Plug 1/4" Brass
Dixon, W2F1-B, W-Series Wingstyle Interchange Female Plug 1/4" BrassDesigned for applications requiring a coupling that can be connected under residual pressure with minimum spillage and air inclusion. Widely used on dump trailer wet-line hydraulic systems and oil field equipment. Not recommended for continuous hydraulic impulse applications.Features:Full Hex- Ease of InstallationVane Valve Guide- Improved Flow PerformanceCompact Body Profile- Reduction of Side-Load StressO-Ring 'Full-Connection' Indicator- Improved Connection EfficiencySwaged Valve Seal- Resistance to Flow DamageConstruction:Machined components are manufactured using solid steel and brass bar stock.Stainless steel retaining rings and springs maximize corrosion resistance and extend service life.Steel componentry is plated using ROHS Compliant Trivalent Chrome.For steel models, coupler valve sleeve and nipple valve are constructed of brassNitrile (Buna-N) seals are standard, providing a temperature range of-40°F to +250°F (-40°C to +121°C).Couplings have a TPC-ET back-up ring on the valve sleeve to extend service life.Nipple valve seal is crimped to improve seal integrity and prolong service life.External O-ring on plug indicates full connection and acts as a contamination shield in connected mode.Redundant O-Ring on the coupler body will engage nipple for secondary sealing support.Compatibility & Interchange Data:Aeroquip 5100-Series, Parker 6100-SeriesSnap-Tite 78-Series, Faster Series-FB, Safeway S51-Series.
Price Comparison
| Seller | Contact Seller | List Price | On Sale | Shipping | Best Promo | Final Price | Volume Discount | Financing | Availability | Seller's Page |
|---|---|---|---|---|---|---|---|---|---|---|
|
BEST PRICE 1 Product Purchase
|
|
$43.47 | $41.94 |
|
$41.94 | See Site | Visit Store |
